Product Code:
AD-074
Weight:
540.00g
Dimensions:
90.00mm x 90.00mm x 23.00mm
Custom Field 1 (UPC):
Protected Link
AD-074 High Temperature Ball Bearing
NOTE: THIS HIGH TEMP BEARING NEEDS TO GREASED REGULARLY WITH AF-013
Single row deep groove ball bearing heat stabilised up to at least 400°C (752 °F). The use of the correct lubricant is crucial in ensuring the optimal performance of bearings and preventing their failure. A high temperature grease, operate as a thin film that protects the components of the bearing.
TO BE USED AS REPLACEMENT FOR AD-066 IN V1 and V2 UNITS - A 3 mm SHIM WASHER HAS TO BE ADDED TO COMPENSATE FOR THE h DIFFERNCE h20 vs h23.
AD-066 IS NO LONGER IN USE WITH THE HOT ROLL
Ø50 x Ø90 x h20 mm
6210 BHTS FB 400°C
810
812
| Spare Part Type | |
|---|---|
| Mechanical Component | |
| Stock Type | |
| Standard Stock | |
